Project description
The design brief and constraints were set by the private technology company Butterfly Energy Systems. The client wanted a new version of the controller for use in a home environment. I needed to specify the device’s features and how a user interacts with it. Then redesign the product’s look and feel.
ideation & sketch notes
Getting ideas across quickly on paper was the key to ideation. Insights from these rough concepts led to the final form. This allowed me to conclude on specific measurements and other design details during the 3D modeling process. This initial process also allowed me to explore simple geometric forms that are suitable for the product.
usability & installment & Material
The Smart Hub controller is detachable; this mobile feature gives the user the freedom to use the controller anywhere in the house.
A built-in leveler was incorporated into the base mount design. This design feature provides guidance to the user when installing the base mount horizontally on the wall.
The front panel and its buttons/symbols are laser cut on stainless steel sheet metal. The functionality of the buttons is thanks to the flexibility of the sheet metal. This front panel design will simplify the manufacturer’s assembling process during production.
base mount & client’s constraints
Since the Smart Hub controller is detachable, charging the controller and uploading essential data can be done through the 4 conductors located at the center of the base mount.
Constraint Parameters:
•Internal area of at least 3.5” x 2.25” x 1”
•Micro SD card slot
•USB port
user interaction & Product features
The user may select any of the features on the control panel. The adjustable knob located in the center is designed as a button and as a dial. The user may use the knob to navigate within the selected feature then press the knob to select sub-level functions.
